EonStor A16F G2221


ID 1903
Categories Data Storage |

Short description EonStor A16F G2221
Price (in €) on request

Manufacturer Infortrend
Model ---
Year of manufacture 0000
Warranty until ---

Long description EonStor A16F G2221

* FC 2G to SATA II RAID subsystem
* ASIC 266 architecture capable of unprecedented read/write performance: 386/310 (MB/sec)
* Enhanced modular enclosure design
* Highest density in 3U rack space for 16 3.5”drives
* Up to 64TB capacity per Logical Drive (LD) (OS dependent)
* DDR Memory up to 2GB

Configuration Model Form Factor
Single A16F G2221 3U Rackmount

Specifications

RAID
Multiple arrays configurable with dedicated or global hot spares
RAID levels supported: RAID 0, 1 (0+1), 3, 5, 10, 30, 50, NRAID, and JBOD
Online expansion by


1. Adding new drives
2. Copying and replacing drives with drives of larger capacity

Automatic background rebuild
Configurable stripe size and write policy per array
Intelligent Drive Handling


* In degraded mode: Skipping irreparable blocks to continue rebuild
* In normal operation: Data block verification and repair
* Task Scheduler: Hands free Media Scan maintenance

System Components


* 3U profile RAID enclosure
* Single RAID controller
* 16 drive trays
* Dual redundant power supplies
* 2 hot swappable, dual speed fan modules
* Optional battery backup unit (BBU) supported

Management
Java based GUI RAID manager
Centralized management of multiple arrays over in band or Ethernet
Event notification: email, LAN broadcast, fax, SMS, MSN, ICQ, or SNMP traps
Host side SES emulation with pass through to back end SES emulation
SNMP 2.0 MIBs with get and set commands
Firmware embedded utility via LCD keypad or RS 232C port
Drive Interface
Up to 1024 LUNs if sufficiently large memory is used with the proper settings
3.5 inch, 1 inch high 3Gbps SATA II disk drives
16 hot swappable drive trays
Automatic bad sector reassignment
Dedicated bandwidth to each connected drive
Host Interface
Auto negotiate FC AL, point to point, or switched fabric
Concurrent I/O commands
Tagged Command queuing up to 256
Variable stripe size per logical drive
Optimization setting for random or sequential I/Os
Maintenance & Availability
Optional Li ION battery support
Immediate array availability
Drive roaming, array configuration on drives
Controller voltage and temperature self diagnostics
Auto Switch cache policy and Auto Shutdown
When a RAID controller detects conditions exceeding preset thresholds, the following actions will be exerted to protect the hardware:


1. Automatically flush cached data and switch the arrays caching mode from write back to write through
2. Commence an auto shutdown

All environmental thresholds associated with this mechanism are user configurable and the caching mode changes back to write back once normal condition is restored.
Physical/Electrical
Interfaces


* 2 SFP sockets, each using a short wavelength adapter
* 2 audio jacks for RS 232C serial port (38400, n, 8, 1) and UPS support
* RJ 45 Ethernet port

Power Supply
2 redundant, hot swappable power supplies with PFC
Input: 100 to 240VAC, 47 to 63Hz
Output: +5V, 32A max.; +12V, 32A max.; +3.3V, 30A max.; 460 Watt capacity
Cooling Fan
4 cooling fans in 2 separate modules
Environmental Specifications

Operating temperature: 5 to 40° C
Non operating temperature: 40º to 60ºC
Relative humidity: 10 to 95%, non condensing
Operating altitude: sea level to 10,000ft

Dimensions:
Chassis dimensions without handles: 131H x 482.6W x 504.3D mm
Chassis dimensions with handles: 130H x 445.0W x 488.2D mm
Package dimensions: 423H x 567W x 772D mm
System weight (w/o drives):
Net weight: 28.5kg
Gross weight: 30.5kg

Weight ---
Dimensions (LxWxH) ---

Location Germany
Region NRW
