Buying: |
EonStor A16F RS1211 |
|||
|
|
||||
|
|
||||
| ID | 1904 | |||
| Categories | Data Storage | | |||
|
|
||||
| Short description | EonStor A16F RS1211 | |||
| Price (in €) | on request | |||
|
|
||||
| Manufacturer | Infortrend | |||
| Model | --- | |||
| Year of manufacture | 0000 | |||
| Warranty until | --- | |||
|
|
||||
| Long description | EonStor A16F R/S1211 * FC to SATA RAID Subsystem * Two 2Gbps hub embedded Fibre Channel host channels per controller * One 2Gbps hub Fibre Channel expansion channel per controller for SATA JBOD expansion * Highest density, 16 drives in 3U rack space * Auto switch cache policy and Auto shutdown * Dual active controllers capable of host transparent failover/failback * Up to 64TB capacity per Logical Drive (LD) (OS dependent) Configuration Model Form Factor ODM/SI Board Dual redundant A16F R1211 3U IFT 7265R 16F2D Single controller A16F S1211 3U IFT 7265R 16F2D Specifications RAID Multiple arrays configurable with dedicated or global hot spares RAID levels supported: RAID 0, 1 (0+1), 3, 5, 10, 30, 50, NRAID and JBOD Online expansion by 1. Adding new drives 2. Copying and replacing drives with drives of larger capacity Automatic background rebuild Configurable stripe size and write policy per array Intelligent Drive Handling * In degraded mode: Skipping irreparable blocks to continue rebuild * In normal operation: Data block verification and repair System Components Redundant, hot swappable components, designed for no single point of failure * One (1) EonStor 3U RAID subsystem enclosure * One (1) RAID controller module [EonStor A16F S1211] or Two (2) RAID controller modules [EonStor A16F R12112] * One (1) 256MB(or above) SDRAM DIMM module (pre installed on the controller module) per controller module * Two (2), hot swappable, redundant, 460W power supply units * Two (2), hot swappable, redundant, dual fan, cooling modules * Sixteen (16), hot swappable, drive trays each with a preinstalled MUX kit * One (1) LCD panel (pre installed on the left side front handle) * Two (2) front handles Management Firmware embedded Java based GUI RAID manager Centralized management of multiple arrays over in band or Ethernet Real time event notification over Email, LAN broadcast, or SNMP traps Host side SES emulation with pass through to back end SES emulation SNMP 2.0 MIBs with get and set commands Firmware embedded utility via LCD keypad or RS 232C (audio jack) serial port Module status LED indicators * Two (2) per drive tray * Two (2) per cooling module * One (1) per power supply unit * Eleven (11) per RAID controller module Onboard alarm is triggered when one of the following modules fails: * RAID controller module * Cooling modules * Power supply unit * Hard drive * Serial port communication with PC hyper terminal Drive Interface Up to 1024 LUNs if sufficiently large memory is used with the proper settings Supports 3.5", 1" high hard disk drives Sixteen (16) hot swappable drive trays Single dual loop across 16 drives within enclosure Automatic bad sector reassignment Drive hot swappable via SCA II connectors Dedicated bandwidth to each connected drive Host Interface Auto negotiate FC AL, point to point, and switched fabric Concurrent I/O commands Tagged Command queuing up to 256 Variable stripe size per logical drive Optimization setting for random or sequential I/Os Maintenance & Availability Firmware rolling upgrade on redundant RAID controllers Synchronized cache over dedicated Fibre channel Comes standard with a Li ION battery module Immediate array availability Drive roaming, array configuration on drives Controller voltage and temperature self diagnostics Auto switch cache policy and Auto shutdown When a RAID controller detects conditions exceeding preset thresholds, the following actions will be exerted to protect the hardware: 1. The cached data will automatically be flushed and the arrays caching mode will be switched from write back to write through 2. Commence an auto shutdown All environmental thresholds associated with this mechanism are user configurable and the caching mode changes back to write back once normal conditions are restored. Physical/Electrical Interfaces: * Five (5) SFP sockets per controller module that use short wavelength adapters * One (1) RJ 45 Ethernet port per controller module * Two (2) RS 232C (Audio Jack) serial ports (38400, n, 8, 1) per controller module (one is for terminal emulation, the other is for UPS support) Power Supply Unit (PSU) modules: Two (2) redundant, hot swappable, 460W, PSU modules with PFC. Input: 90 ~ 260VAC 47 ~ 63Hz Output: (Maximum output: 460 Watts) +12.0V 32A max. + 5.0V 25A max. + 3.3V 20A max. Dimensions: 248.9D x 128.8W x 81.6H mm Cooling Modules: Two (2), redundant, hot swappable, dual fan, cooling modules Fan speed: 3600rpm Fan size: 9.7cm Airflow per cooling module: 61 CFM * Note there are a total of four fans (two in each cooling module) Environmental Specifications: Operating temperature: 5 to 40°C Non operating temperature: 40º to 60ºC Relative humidity: 10~95%, non condensing Operating altitude: sea level to 10,000ft Dimensions: * Without protrusions: 131H x 446.2W x 500D mm * With protrusions: 131H x 485W x 532D mm Package dimensions: 476H x 592W x 695D mm System weight (w/o drives): * Net weight: 20kg * Gross weight: 32kg |
|||
|
|
||||
| Weight | --- | |||
| Dimensions (LxWxH) | --- | |||
|
|
||||
| Location | Germany | |||
| Region | NRW | |||
|
|
||||
|
|
||||
|
|
||||
| View this article on the vendor's web site. | ||||
