Buying: |
EonStor A16U G2421 |
|||
|
|
||||
|
|
||||
| ID | 1908 | |||
| Categories | Data Storage | | |||
|
|
||||
| Short description | EonStor A16U G2421 | |||
| Price (in €) | on request | |||
|
|
||||
| Manufacturer | Infortrend | |||
| Model | --- | |||
| Year of manufacture | 0000 | |||
| Warranty until | --- | |||
|
|
||||
| Long description | EonStor A16U G2421 * Market leading I/O performance o Sustained RAID5 Read/Write: 515/365 (MB/sec) * Ultra high density, 3U profile, 16 bay enclosure * Up to 8TB of storage capacity * Two (2) SCSI 320 host channels * Support up to 2GB DDR RAM * Optional, hot swappable battery backup unit (BBU) * Ease of maintenance with host swappable FRUs Host to Drive Interface Model Form Factor SCSI 320 to SATA II A16U G2421 3U rack mount Specifications RAID * Multiple arrays configurable with dedicated or global hot spares * RAID levels supported: RAID 0, 1 (0+1), 3, 5, 6, 10, 30, 50, 60, NRAID and JBOD (for A16U G2421 1) * RAID levels supported: RAID 0, 1 (0+1), 3, 5, 10, 30, 50, NRAID and JBOD (for A16U G2421) * Online expansion by: o Adding new drives o Copying and replacing drives with drives of larger capacity * Automatic background rebuilds * Configurable stripe size and write policy per array * Intelligent drive handling: o In degraded mode: skips irreparable blocks to continue rebuild o In normal operation: data block verification and repair Host Interface * Two (2) SCSI 320 through four (4) VHDCI 68 pin SCSI ports; SCSI 160 backward compatible * Concurrent I/O commands * Tagged command queuing up to 256 * Variable stripe size per logical drive * Optimization setting for random or sequential I/Os Drive Interface * Sixteen (16) hot swappable drive trays that accommodate 1 inch pitch, 3.5 inch SATA II or SATA I disk drive * Automatic bad sector reassignment * Dedicated bandwidth to each connected drive System Components Single controller configuration provides full RAID functionalities * One (1) EonStor ® enhanced 3U enclosure * One (1) RAID controller module * One (1) 256MB DDR RAM DIMM module (pre installed on the controller module) * Two (2), hot swappable, redundant, 460W power supply units * Two (2), hot swappable, redundant, dual fan cooling modules running in high/low speeds * Sixteen (16), hot swappable drive trays * Two (2) front handles * Optional battery backup unit (BBU) supported Management * Front LCD control panel for setup and configuration * 10/100 BaseT Ethernet for out of band management * Two (2) COM ports for local access to firmware embedded utility and UPS connectivity * Firmware embedded Java based RAIDWatch ® GUI manager: o VT 100 terminal emulation via RS 232C o Telnet access via onboard Ethernet port o Cross platform, remote administration with SSL o Out of band access via Ethernet (GUI onboard) o Centralized management to monitor and administer multiple RAID units on one screen * Configuration client for real time event notification over Email, Fax, LAN broadcast, SNMP Traps, MSN mess en ger, ICQ, SMS short messages, and the configuration utility screen * SNMP agent support: o SNMP trap event notification with plain text event message (no MIB file required) o SNMP V2.0 MIB file support with get and set commands Indicators * Onboard alarm is triggered when one of the following modules fails: o RAID controller module o Cooling module o Power supply unit o Hard drive o Optional BBU module * Module status LED indicators: o Two (2) per drive tray o Two (2) per cooling module o One (1) per power supply unit o One (1) per optional BBU module o Three (3) per LCD panel o Four (4) per RAID controller module o Two (2) per Ethernet port * Module failure alert through I2C bus Infortrend Smart Technologies Derived from more than ten years experience in RAID storage design, Infortrends innovative firmware delivers Smart technologies that provide enhanced storage solutions for every customer environment, from small organizations to large enterprises. These technologies enhance I/O processing, drive handling, and system management. IOSmart IOSmart allows for the flexible configuration of logical drives, logical volumes and logical partitions and ensures instant RAID availability via background logical drive initialization. Fibre loops load balancing is provided within the subsystem. The firmwares embedded intelligent algorithms, such as Adaptive Write Policy and Guaranteed Latency I/O, improve sequential write performance and ensure the fast and continuous flow of data. DrvSmart The DrvSmart utility provides an easy way to store data while keeping it safe. One of the main DrvSmart functions, Media Scan, retrieves data from degraded or damaged hard drives and handles low quality drives in both the degraded mode and during the rebuild process. Other DrvSmart features include disk cloning, drive roaming, SMART, transparent resetting of non responsive hard drives, and RAID parity update tracking and recovery. SysSmart In addition to RAID protection for the disk drives, Infortrend has introduced Auto Data Protection Mechanisms. These special SysSmart firmware functions ensure data safety by automatically switching to write through data caching when abnormal subsystem conditions are detected such as a PSU/cooling module failure, low BBU or UPS battery charge, etc. By using the firmware to monitor and control the enclosures dual speed fans, the fan rotation speed is raised to a higher level when critical conditions are detected, e.g., a PSU or fan failure. Fan speed returns to the lower setting when normal operating status is restored. The ES A16U G2421 1 can be monitored by variety of utilities and approaches. I 2 C internal serial bus, SAF TE, and SES are seamlessly integrated into the comprehensive Java based GUI RAIDWatch Manager. Component status, voltage and temperature readings, and system events are instantly revealed through the managers graphical interface. Physical/Electrical Interfaces * Four (4) ports in two (2) dual stacked VHDCI SCSI connectors * Two (2) COM ports (38400, n, 8, 1) * One (1) 10/100BaseT Ethernet port Power Supply Module Two (2) redundant hot swappable power supplies with PFC Input 100VAC at 10A, 240 VAC at 5A with PFC (auto switching) 47 ~ 63Hz Output (Maximum output: 460 Watts) +12.0V 32A max. + 5.0V 32A max. + 3.3V 30A max. Dimensions: 248.9(D) x 128(W) x 82.1(H) mm Cooling Module Two (2) redundant dual fan cooling modules Maximum air flow High speed: 31.78 DFM Low speed: 20.13 CFM Dimensions: 263.7(D) x 123.2(W) x 36.4(H) mm Environmental Specifications Operating temperature 0° to 40°C Non operating temperature 40º to 60ºC Relative humidity: 5 ~ 95%, non condensing Operating altitude: Operating: 0 ~ 12,000 ft Non operating: 0 ~ 40,000 ft Dimensions * Chassis without handles: 445(W) x 130(H) x 487(D) mm * Chassis with handles: 483(W) x 131(H) x 535(D) mm * Package: 423H x 567W x 772D mm System Weight * Net weight: 28kg * Gross weight: 31kg Spare Parts: As certified matchpart GmbH (Germany) Distributor we provide spare Parts. This item is without packaging: Not New Sale according to §7 of our AGB, which can bei downloaded here www.brakensiek.com/AGB.pdf Delivery Service: At additional cost our Partner Systembau Dortmund GmbH & Co. KG packs and delivers this item if possible at the same day. Repair: Our Partner matchpart GmbH (Germany) offers circuit board repair service. If you are interested for a product you already own, we need serial number, YOM, sparepartnumber and type of error. Service Training: A Service Technician Training is available on request by matchpart GmbH (Germany). This training is neccessary if you want to install certified matchpart parts in exchange with warranty. Package Deals welcome: Please make us an reasonable offer for a package deal. Recertification: Brakensiek Systemhaus GmbH & Co. KG is ISO 9001 certified for the service of recertification. Please contact us for a quote if you need a recertification. Trade In/We are looking for machines: We offer Trade In prices. If you have machines for sale, please offert them to us. You have to cover the transport costs. Supplies: Please ask for supplies. Manuals: The manual will be send as PDF and the original one will be shipped at additional cost. Information for buyers: This machine is sold. You find other machines on our website. Please use the search button on our website. Our offers are changing daily. |
|||
|
|
||||
| Weight | --- | |||
| Dimensions (LxWxH) | --- | |||
|
|
||||
| Location | Germany | |||
| Region | NRW | |||
|
|
||||
|
|
||||
|
|
||||
| View this article on the vendor's web site. | ||||
