APC Smart UPS 5000VA 5 HE 230V


ID 2529
Categories Server Room |

Short description APC Smart UPS 5000VA 5 HE 230V
Price (in €) on request

Manufacturer APC
Model ---
Year of manufacture 0000
Warranty until keine

Long description APC Smart UPS 5000VA 230V 5U

Non new

Model SU5000RMI5U

The UPS is connected securely to the house wiring!

Hardwire the electrical connections

Caution:
The electrical connections must be performed by a qualified electrician in accordance with national and local regulations
be executed. BEFORE check the Hardwire the UPS if the power cable with a 25 amp circuit breaker
is equipped.
Ensure that the batteries are installed only in the UPS when the wiring is complete.
An easily accessible Trenn /Abschaltgerät integrate into the wiring diagram.

APC Smart UPS, 5000VA/3750W, Input 230V / Output 230V, Interface Port DB 9 RS 232, RJ 45 10/100 Base T, SmartSlot, Rack Height 5 U


Specifications

Output power capacity:
5000 V

Output power capacity:
3750 Watt

Maximum achievable power:
5000 VA

Maximum achievable power:
3750 Watt

Rated output:
230V

Output Voltage Rating:
Configurable for a rated output voltage of 220, 230 or 240 V

Output Voltage Distortion:
Less than 5% at full load

Output Frequency (sync):
47 53 Hz for 50 Hz nominal, 57 63 Hz for 60 Hz nominal

Crest Factor:
up to 5: 1

Shaft Type:
Sinewave

Output Connections:
(8) IEC 320 C13
(2) IEC 320 C19
(6) IEC Jumpers


Input

Nominal Input Voltage:
230V

Input frequency:
50/60 Hz + / 3 Hz (auto sensing)

Input Connections:
Hard Wire 3 wire

Input voltage range for main operations:
174 to 286 V

Input voltage adjustable range for main operations:
168 to 302 V

Batteries & Runtime

Battery Type:
Maintenance free sealed Lead Acid battery with suspended electrolyte: leakproof

Recharge time:
RBC12

Number of spare batteries (RBC â„¢):
2

Typical backup time at half load:
18.8 minutes (1875 Watts)

Typical backup time at full load:
5.7 minutes (3750 Watts)

Runtime Chart:
Smart UPS

Communications & Management

Interface:
DB 9 RS 232, RJ 45 10/100 Base T, Smart Slot

Control panel:
LED status display with bar charts for load and battery and indicate power, Replace Battery and Overload

Audible Alarm:
when on battery: distinctive low battery alarm: configurable delays

Surge Protection and Filtering

Surge energy rating:
480 Joules

Filtering:
Multipole full time noise filtering: 0.3% IEEE surge let, Nullabfangung response time: meets UL 1449

Dimensions

Maximum height:
8.75 inches (222 mm)

Maximum width:
19:00 inches (483 mm)

Maximum depth:
25.00 inches (635 mm)

Rack Height:
5 U

Net weight:
205.00 pounds (lbs.) (93.18 kg)

Color:
Beige

Environment

Operating Environment:
0 40 ° C (32 104 ° F)

Relative Humidity:
0 95%

Operating Elevation:
0 10000 feet (0 3000 meters)

Storage Temperature:
15 45 ° C (5 113 ° F)

Storage Relative Humidity:
0 95%

Storage Elevation:
0 50000 feet (0 15000 meters)

Online Thermal Dissipation:
430 BTU / hr

Weight ca. 100kg
Dimensions (LxWxH) ---

Location Germany
Region NRW
