Selling:

Demo machine with coating unit


ID 3000
Categories Press |  Sheet-Fed Offset Presses |

Short description Demo machine with coating unit
Price (in €) on request

Manufacturer KBA Druckmaschinen
Model Genius 52UV (2011)
Year of manufacture 2011
Warranty until ---

Long description Genius 52 UV demo maschine with coating unit from a waterless printing centre

The machine has been used for test and demo purposes only. In a technical and optical excellent condition.


Year of manufacture: 2011
Milage: 150.000 Sheets
List price Manufacturer: 650.000 Euro

Includes additional items / equipment:

• Die cutting device for plate punching and bending
• Control planel / light table with D65 lighting
• Ducting and exhaust fans
• Platform construction (1.3 x 2.4 m / 51.18 x 94.5“) made of studded steel plates with a tubular frame sub construction to cowl the ducting and exhaust fans – including ca. 10 meters (393.7”) galvanised straight tubes.
• Starters kit

General
Printing system: waterless offset printing
Printing units: 5
Inks: UV curing inks
Print substrates: from 0.1 to 0.8 mm (0.004 to 0.03“), (depending on substrate) PVC, ABS, PS, PE, PET, PC, carton and paper
Coating unit: Squeeze coater with downstream UV dryer

Performance: max. 8.000 sheets/hour (depending on print substrate)

Stack height
Sheet feeding: 600 mm (23.62“) max.
Sheet delivery: 400 mm (15.75“) max.

Formats
Max. sheet format: 360 x 520 mm (14.2 x 20.47“)
Min. sheet format: 210 x 297 mm (8.27 x 11.69“)
Max. printing format: 350 x 500 mm (13.78 x 19.69“)
Gripper edge: 10 mm (0.39“)

Printing plates: waterless, analog or digital
Format / thickness: 404 x 540 x 0.3 mm (15.91 x 21.26 x 0.0118“)
Plate change: semi automatic, register true, complete plate change in less than 5 minutes

Length x Width x Height: 4,850 x 5,400 x 1,910 mm (190.94 x 153.54 x 75.2“)
Total weight: 7.25 tons (approx. 16.000 lbs)
Air consumption: 1500 l/min (7 bar / 101.5 psi)

Power connection
Connected load: 3 x 400 V / 230 V (± 10 %) TN S net, 50 Hz
Electric power: 38 kVA
Amperage: 55 A
Backup fuse: 3 x 100 A

Offer price: 450.000 Euro netto

Delivery time: Immediately available
Delivery conditions: Ex works

Highlights:
• Printing times can be planned for available printing plate sets
• Job changeover in no more than 7 minutes
• Around ten sheets of run up waste
• 1:1 ink transmission by cylinders of identical diameter results in ghosting free prints
• Consistently high printing quality from the first to the last print with the anilox short inking unit. Inking is held constant by temperature control over the entire sheet width
• Excellent register stability thanks to gripper bite
• Urgent printing jobs are possible at short notice
• Lower production costs due to smaller footprint of less than 12 m2
• New business fields made possible by high flexibility with extreme substrates

More general product information: http://www.kba.com/en/sheetfed offset/sheetfed offset presses/product/genius 52uv/detail/

Weight 7.25 tons (approx. 16.000 lbs)
Dimensions (LxWxH) 4,850 x 5,400 x 1,910 mm (190.94 x 153.54 x 75.2ï

Location Germany
